The DIS station offers the complete solution for the desoldering of circuit repair with insertion components for solder extraction.
It’s also necessary for cleaning the pads in SMD circuits. The station includes all basic advantages and characteristics featured in the rest of our JBC stations.
Like sleep and hibernation, temperature limits, PIN blocking, etc.
Both control units are designed for production and rework applications with medium and light thermal requirement.
DIS station are provided with extra built-in features to personalize hibernation, sleep settings and temperature limits. All parameters can be blocked with a PIN.

The station is composed by DI-2A control unit, DR-A desoldering iron with C560-003 tip, DR-SA Stand, MS-A suction module electric system.

Description unit:
Temperature selection between 90°C- 450°C
Nominal Power: 2 x 75W
Peak Power: 2 x 140W
Weight 5,3Kg
Sleep Mode
Hibernation
